Automatic Liquid Filling Machine

Description

This automatic filling machine is with larger air cylinder which can help to fill liquid faster.This machine is easy to operate and each nozzle can be controlled separately,it can work with the capping machine,labeling machine to achieve to automatic production line,helps you improve working efficiency.

This series of liquid & paste filling machine is suitable for filling different types of liquid & paste products in daily chemical, food, grease, medicine, pesticide and other industries. The piston injection filling and three way one-way valve device has the advantages of high filling accuracy, convenient installation and debugging, simple cleaning and cleaning, and no leakage.

This automatic filling machine is with larger air cylinder which can help to fill liquid faster.This machine is easy to operate and each nozzle can be controlled separately,it can work with the capping machine,labeling machine to achieve to automatic production line,helps you improve working efficiency.

Specification

Product name: Automatic Bottle Filling Machine

Model: BR-YT4T

Filling material: Beer, Milk, Water, Oil, Juice, Other

Filling range: 100-1000ml (Optional model: 5-100ml 10-300ml 50-500ml 100-1000ml 500-3000ml 1000-5000ml）

Filling precision: +/-1% or less

Filling nozzles: 4 nozzles (2/4/6/8 nozzles can be customized)

Filling speed: 10-40 bottles/min(1000-1200bph)

Air pressure: 0.5-0.7Mpa

Voltage: AC220/110V 50-60Hz

Power: 400W

Material: Stainless Steel

Machine size: 2000*1050*1650mm

Weight: 380KG

Details

1.With touch screen control panel, it is more convenient to adjust different kinds of parameter. The visual working data makes the adjustment can be more accurate. This control panel can be set into English version, which can help you control the machine faster.

2.With multiple nozzle, each filling nozzle can be controlled separately. It is with anti-dripping design, this ensure the cleanliness during production, improve production quality. This machine can be customize into 2/4/6/8 filling nozzle according to your needs, if you need this please contact us.

3.The working height of this machine can be adjusted by rotary knob, this makes sure the machine is suitable for different kinds of bottles, widen the application range.

4.The sensor is designed for detecting bottles when they pass through, prevent from missing or wasting bottles, improves the fillng accuracy.

5.The conveyor belt can ensure the product will be transferred more smoothly and faster, the conveyor length can be customized according to your needs, meet the need of mass production.

6.This machine need to work with the air compressor, if you need this please contact us. This machine components can help to filter impurities, ensure the machine work stably.
